Endotracheal tubes

Shiley™ evac endotracheal tube with TaperGuard™ cuff

<p>The Shiley™ evac endotracheal tube with TaperGuard™ cuff technology incorporates evac technology for subglottic secretion drainage.</p>

Features

Manage secretions with advanced airway protection.

The Shiley™ evac endotracheal tube with TaperGuard™ cuff technology features an integrated suction lumen and evacuation port and provides a safe, convenient way to suction the subglottic area above the cuff. This technology, when used in conjunction with a VAP bundle, has been shown to reduce VAP by an average of 50%.1–3

Discover the advantages of Taperguard™ cuff technology

The low-impact, low-pressure endotracheal tube

Endotracheal tubes with TaperGuard™ cuff technology have features that may help reduce the tracheal impact of intubation with a unique, taper-shaped cuff design that provides a smaller area of contact with the patient’s airway than traditional barrel-shaped cuffs.4  The unique TaperGuard™ cuff design:

  • Exerts 29% less pressure on the trachea4,5
  • Reduces intracuff pressure required to obtain an adequate seal compared to traditional cuffed tubes4,6
  • Provides more uniform pressure distribution than traditional cuffed tubes at equivalent intracuff pressures4,7
  • Reduces microaspiration by as much as 90% compared to traditional cuffed tubes4,7
See a product image of the Shiley™ endotracheal tube with Taperguard cuff.

Ordering information

Shiley™ evac endotracheal tube with TaperGuard™ cuff

Item number ID (mm) OD (mm) Units per box
18860 6.0 9 10
18865 6.5 9.8 10
18870 7.0 10.4 10
18875 7.5 11.2 10
18880 8.0 11.8 10
18885 8.5 12.6 10
18890 9.0 13.1 10

Shiley™ evac endotracheal tube with TaperGuard™ cuff, with preloaded stylet

Item number ID (mm) OD (mm) Units per box
18860S 6.0 9 10
18865S 6.5 9.8 10
18870S 7.0 10.4 10
18875S 7.5 11.2 10
18880S 8.0 11.8 10
18885S 8.5 12.6 10
18890S 9.0 13.1 10

Similar products

  1. Based on benchtop test report 090352, Mallinckrodt™ TaperGuard™ evac endotracheal tube 510(k).

  1. Muscedere J, Rewa O, McKechnie K, Jiang X, Laporta D, Heyland DK. Subglottic secretion drainage for the prevention of ventilator-associated pneumonia: a systematic review and meta analysis. Crit Care Med. 2011;39(8):1985–1991.
  2. Pozuelo-Carrascosa DP, Herráiz-Adillo Á, Alvarez-Bueno C, Añón JM, Martínez-Vizcaíno V, Cavero-Redondo I. Subglottic secretion drainage for preventing ventilator-associated pneumonia: an overview of systematic reviews and an updated meta-analysis. Eur Respir Rev. 2020;29(155):190107.
  3. Mahmoodpoor A, Hamishehkar H, Hamidi M, Shadvar K, Sanaie S, Golzari SE, Khan ZH, Nader ND. A prospective randomized trial of tapered-cuff endotracheal tubes with intermittent subglottic suctioning in preventing ventilator-associated pneumonia in critically ill patients. J Crit Care. 2017;38:152-156.
  4. Seegobin RD, van Hasselt GL. Endotracheal cuff pressure and tracheal mucosal blood flow: endoscopic study of effects of four large volume cuffs. Br Med J (Clin Res Ed). 1984;288(6422):965–968.
  5. Lichtenthal PR, Wood L, Wong A, Borg U. Pressure applied to tracheal wall by barrel and taper shaped cuffs. American Society of Anesthesiologists Annual Meeting. 2011:A1054.
  6. Guard endotracheal tube intracuff pressure increase is less than that of the Hi-Lo tube during nitrous oxide exposure: a model trachea study. Anesth Analg. 2013;116: 609–612.
