| Item number | Description | Units per box |
|---|---|---|
| PMC40M | Microstream™ CO2 NanoPod | 1 |
| PMC40M-SF-NK | Microstream™ CO2 NanoPod for nihon kohden | 1 |
Capnography OEM solutions
Microstream™ CO₂ NanoPod OEM module
The Microstream™ CO₂ NanoPod enables users to integrate all the trusted features of Microstream™ capnography into existing patient monitoring platforms.
Features
The horizontal or vertical mounting options with a cradle help meet host monitor design and care area requirements. The module can be removed from the cradle for enhanced flexibility. Once the module is integrated with the monitor, clinicians can simply attach a Microstream™ Advance filter line and begin monitoring patients.
Specifications
Accuracy
| CO2 partial pressure (at sea level) accuracy | |
|---|---|
| 0–38 mmHg | ± 2 mmHg |
| 39–99 mmHg | ± (5% of CO2 reading + 0.08 × CO2 reading – 39 mmHg) |
| 100–150 mmHg | ± 0.43% x ambient pressure + 8% × CO2 reading |
| Respiration rates range 0–50 bpm | |
| 0–70 bpm | ±1 bpm |
| 71–120 bpm | ±2 bpm |
| 121–150 bpm | ±3 bpm |
| Performance | |
| CO2 sampling flow rate | 50 mL per minute (±5 ml per minute) flow measured by volume |
| Initialization time | Typically, 30 seconds to obtain both reading and waveform. At full accuracy when value first appears. |
| Respiration rate | 0–150 breaths per minute |
| Intended population | Adult, pediatric, neonatal |
| Physical characteristics | |
| Dimensions | 60 mm (w) × 94 mm (l) × 58 mm (h) |
| LEMO and mating connector | |
| LEMO part number | PFG.M0.7GL.AC52GZ |
| Mating connector part number | PNG.M0.7GL.LG |
| Power requirements | |
| Input voltage | 4.5–5.5 V |
| Current: mA (maximum peak) | 700 Maximum duration: 200 ms |
| Power [MW] (typical average) | 1,200 RMS power for the average unit |
| Power [MW] (maximum average) | 1,350 RMS power for the worst-case unit |
Environmental
| Temperature | |
|---|---|
| Operating | 0–40 C (32–104 F) |
| Storage | -40–70 C (-40–158 F) |
| Operating pressure and altitude | |
| Pressure | 57 kPa to 108 kPa (430 to 805 mmHg) |
| Altitude | -487 m to 4,572 m (-1,600 to 15,000 ft) |
| Storage pressure and altitude | |
| Pressure | 11 kPa to 108 kPa (88 to 805 mmHg) |
| Altitude | -487 m to 15,240 m (-1,600 to 50,000 ft) |
| Relative humidity | |
| Operating and storage | 10–95% (noncondensing) |
| Interface requirement | |
| Communication protocol | RS232, Oridion protocol |
| Compliance standards | |
IEC 60601-1 (Ed. 3.2): 2020 IEC 60601-1-2 (Ed. 4.1): 2020 ISO 80601-2-55:2018 IEC 60601-1-6:2013 IEC 62304:2015 |
|
Ordering information
