Neurostimulation systems

Vanta™ neurostimulation system

0:00 / 0:00

Neurostimulation systems

Vanta™ neurostimulation system

Vanta™ is a recharge-free neurostimulation system that aids in the management of certain types of chronic, intractable pain.

Ordering information
Contact a representative
Indications, Safety, and Warnings

Description

High-performance recharge-free neurostimulator

The Vanta™ spinal cord stimulation (SCS) system is a high-performance recharge-free device offering optimized longevity.

Features

Advanced programming

  • Electrode redistribution: precisely balances stimulation over the electrodes offering personalized stimulation for each patient
  • Efficient electrode combinations: rapidly scans the electrodes to help identify the optimal electrode combination on each lead
  • Snapshot™ reporting, powered by AdaptiveStim™ technology allows physicians to objectively monitor a patient‘s progress
  • Fluoroscopy image library: quick access to images
  • 5.5–7.5 years of recharge-free longevity estimated using actual 12-month Differential Target Multiplexed™ (DTM™) spinal cord stimulation (SCS) endurance therapy programming data1
  • Approximately 2× longer-lasting than other devices at comparable settings†,‡
  • In-app longevity estimator: helps manage recharge-free longevity with confidence
  • SureScan™ MRI technology allows MRI scans anywhere on the body§ enabling diagnostic care
  • Provide patients with the same conditional MRI access as non-implanted patients§ — now and in the future
The Vanta™ neurostimulation system is a recharge-free spinal cord stimulation system that aids in the management of certain types of chronic, intractable pain.

Creating connections

The Medtronic adaptor extension connects with certain Boston Scientific or Nevro leads. This enables patients with existing leads to gain access to meaningful pain relief with DTM™ SCS endurance therapy offered with recharge-free convenience on Vanta™ INS.

Download the details (open in new window)

Compatible products and features

  • MyStim™ PC smart patient therapy app Model A72200
  • Clinician programmer model CT900 with software app A71200 and trialing app A71300
  • 16-electrode Specify™ SureScan™ MRI surgical leads
  • Vectris™ SureScan™ MRI percutaneous leads
  • Injex™ anchoring system Models 97791 and 97792

Ordering information

Neurostimulator

Item number Description
977006 Vanta™ with AdaptiveStim™ technology recharge-free neurostimulator

Patient programmer

Item number Description
HH9020SCS MyStim™ PC smart patient programmer with application A72200 for patients to adjust settings and parameters
TM91SCS MyStim™ PC smart patient programmer SCS communicator
B37120 MyStim™ PC smart patient accessory case
CASEA10E MyStim™ PC patient programmer and communicator case

Accessories

Item number Description
B31060 Vanta™ connector plug kit

Resources

Hear from Jay and Sandra about their experiences with Vanta™ SCS systems.

Jay and Sandra: Vanta™ neurostimulation system patient testimonial (02:59)

Similar products

† Settings used from Proclaim™ clinician manual. Nominal settings 12 hours per day: 50-Hz frequency. 225-μs pulse width, and 5-mA amplitude at 500-ohms impedance. Energy modeling is the same for Model 3660 and Model 3670.

‡ Settings from Boston Scientific Alpha™ instructions for use. Programmed at 4.1mA, 280us. 40Hz. 1 area, 730 Ohms, 2 contacts.

§ Under specific conditions. Refer to product labeling for full list of conditions. Patients with non-Medtronic leads and an EMBSNV20 adaptor extension are not eligible for an MRI.

  1. Provenzano, Peacock, Fishman, et al. A prospective multi-center study of a reduced-energy DTM™ stimulation derivative: Long-term outcomes in therapy naïve patients. Poster presented at: American Society of Regional Anesthesia and Pain Medicine (ASRA) Annual Pain Medicine Meeting; November 17–19, 2022; Orlando, FL, United States.
  2. Desai MJ, Hargens LM, Breitenfeldt MD, et al. The rate of magnetic resonance imaging in patients with spinal cord stimulation. Spine. 2015;40(9):E531–537
