Crescent™ jugular dual-lumen catheter

<p>The Crescent™ catheter is a bicaval-designed dual lumen catheter available in sizes 24, 26, 28, 30, and 32 Fr. Used for long-term ECMO.</p>

Ordering information
Contact a representative

Features

Game-changing flow2 for ECMO

The Crescent™ catheter is the first FDA-cleared, jugular dual lumen long-term ECMO line of catheters. The catheter allows for more accurate placement1 with just one cannulation site, delivers enhanced flow dynamics2, and helps maintain optimal flow3 once placed.

Device features

Correct placement made easier1

Optimal flow begins with correct placement, and that can be challenging. The Crescent™ jugular dual-lumen catheter was designed to address those challenges with features that make positioning1 and securement3 easier.  

Radiopaque markers for improved visualization

Visible under radiographic imaging, radiopaque markers aid in positioning the catheter and identifying drainage sites, infusion port, catheter tip, and axial orientation of the port.

  1. Superior vena cava (SVC) drainage marker
  2. Radiopaque markers at infusion site
  3. Inferior vena cava (IVC) drainage marker
  4. Catheter tip marker
This is an image demonstrating how radiopaque markers aid in positioning the Crescent™ jugular dual-lumen catheter.

Optimized flow rates2

Enhancements in port placement, lumen design, and tip geometry give the Crescent™ catheter optimal flow efficiency. This enables higher flow at lower pressure and allows for lower rates of hemolysis and recirculation2.

Crescent™ flow curves

This is a chart of the Crescent™ jugular dual-lumen catheter flow curves.
The crescent-shaped lumen helps optimize pressure flow performance, and advanced materials make the catheter strong, flexible, and kink-resistant on the Crescent™ jugular dual-lumen catheter.

Enhancements for optimal flow

The crescent-shaped lumen helps optimize pressure flow performance, and advanced materials make the catheter strong, flexible, and kink-resistant.

This is a close-up of the infusion port on the Crescent™ jugular dual-lumen catheter.

Promotes directional efficiency

The large infusion port, combined with radiopaque markers for placement accuracy, helps ensure flow is directed toward the tricuspid valve.

This is a close-up of the drainage and reinfusion ports on the Crescent™ jugular dual-lumen catheter.

Helps minimize recirculation

Drainage and reinfusion ports are designed to mimic the body’s natural flow ratios to minimize recirculation while maintaining flow3.

Maintaining desired flow

Maintain desired flow with features that help keep the catheter securely in place during patient ambulation. Enhanced visualization makes it easy to verify that the device remains properly positioned.

  • Visual verification of placement
    Improved visualization helps quickly identify the catheter tip and orientation of the reinfusion port, while verifying that accurate positioning is maintained over the course of the case.
  • Extended tip design helps maintain position
    The tip of the catheter sits deeper in the IVC, reducing the chance of migration outside of the IVC.
This is a close-up of the elongated tip on the Crescent™ jugular dual-lumen catheter.

Durable securement3

  1. In select circumstances, sutures may be placed on the connectors.
  2. The bifurcation suture site provides security against catheter translations.
  3. The integrated suture site contains special reinforcement to protect against catheter damage.
  4. The optional suture collar can be placed at a desired location on the catheter body before or after catheter insertion.
This is an image of the securement of the Crescent™ jugular dual-lumen catheter, including bifurcation suture site, integrated suture site, and optional suture collar.

Vascular access

Expanding options for vascular access

The Opus™ vascular access kit offers a convenient solution for the vascular access you need.

  • Facilitates serial dilation for peripheral cannulation via the Seldinger technique
  • Compatible with single lumen arterial and venous cannulae, and Crescent™ jugular dual-lumen catheters
  • Includes a range of dilator sizes, 8 Fr to 28 Fr
This is an illustration of the Opus™* vascular access kit.

Five sizes available for varying patient anatomies

  • Crescent™ catheters are available in sizes 24 Fr to 32 Fr. 
  • Each sterile pouch contains one Crescent™ catheter with an introducer, drainage cap, suture collar, and matching dilator on a holding card.
This is an illustration of the Crescent™ jugular dual-lumen catheter sterile package, which contains one Crescent™ catheter with an introducer, drainage cap, suture collar, and matching dilator on a holding card.

Ordering information

Item number Size (Fr / mm) Insertion length (cm) Connector (in) Units per carton
70124 24 / 8.0 30 3/8 1
70126 26 / 8.7 30 3/8 1
70128 28 / 9.3 34 3/8 1
70130 30 / 10.0 34 3/8 1
70132 32 / 10.7 34 3/8 1

Resources

Similar products

  1. Compared to products without radiopaque markers. Design verification and validation data on file. These tests may not be indicative of clinical performance.
  2. Bench and animal data on file. These tests may not be indicative of clinical performance
  3. Design verification and validation data on file. These tests may not be indicative of clinical performance.
