Coronary diagnostic catheters

DxTerity™ TRA diagnostic catheter

<p>The DxTerity™ TRA cardiac and vascular diagnostic catheters are indicated to deliver radiopaque media, guidewires and therapeutic agents to selected sites.</p>

Ordering information
Contact a representative

Features

Product details

Learn about the TRApease curve, a relaxed secondary curve that allows for easy engagement of the coronary artery ostia and includes additional tertiary curve for added support.

TRApease curve

Relaxed secondary curve allows for easy engagement of the coronary artery ostia and includes additional tertiary curve for added support

Sizing: 3.5, 4.0, 4.5

Discover the TRAnsformer curve, which provides excellent support from the aortic root and offers more reach to engage the coronary artery ostia.

TRAnsformer curve

Provides support from the aortic root and offers more reach to engage the coronary artery ostia

Sizing: 3.5, 4.0, 4.5

The ultra curve is a relaxed secondary curve that allows for easy engagement of the coronary artery ostia.

ULTRA curve

Relaxed secondary curve allows for easy engagement of the coronary artery ostia. Simple clockwise and counterclockwise rotations to engage the RCA

Sizing: 3.5, 4.0, 4.5

Learn about the TRActive curve. The 30-degree soft tip after the primary curve allows it to engage the coronary artery ostia.

TRActive curve

30-degree soft tip after the primary curve, allowing it to engage the coronary artery ostia

Sizing: One size fits all

Discover the TRAcker curve, which provides excellent support from the contralateral wall and aortic root leverage.

TRAcker curve

Provides support from the contralateral wall and aortic root leverage

Sizing: One size fits all

DxTerity™ TRA catheters engage both coronaries without catheter exchange1 and feature:

  • Unique, ergonomic, winged hubs3 for easy manipulation1
  • Solid shaft construction for efficient torque and excellent overall catheter performance1
  • Double-braid wire for enhanced torque, strength, and kink resistance1
  • InSlide™ polymer additive for superior lubricity4 and enhanced deliverability1
  • Soft, atraumatic4, radiopaque tip for visibility5
  • Large lumen for high flow of contrast media4 to increase visualization1

Ordering information

DXTerity™ TRA diagnostic catheter 5 Fr

Style Item number Curve size Length (cm) Sideholes
TRAcker U5TRACK TRACK 3.5 100 0
U5TRACKSH TRACK 3.5 100 2
U5TRACKSHA TRACK 3.5 110 2
TRActive U5TRACT TRACT 100 0
U5TRACTSH TRACT 100 2
U5TRACTSHA TRACT 110 2
TRAnsformer U5TRAN35 TRAN 3.5 100 0
U5TRAN35SH TRAN 3.5 100 2
U5TRAN35SHA TRAN 3.5 110 2
U5TRAN40 TRAN 4.0 100 0
U5TRAN40SH TRAN 4.0 100 2
U5TRAN40SHA TRAN 4.0 110 2
U5TRAN45 TRAN 4.5 100 0
U5TRAN45SH TRAN 4.5 100 2
U5TRAN45SHA TRAN 4.5 110 2
TRApease U5TRAP35 TRAP 3.5 100 0
U5TRAP35SH TRAP 3.5 100 2
U5TRAP35SHA TRAP 3.5 110 2
U5TRAP40 TRAP 4.0 100 0
U5TRAP40SH TRAP 4.0 100 2
U5TRAP40SHA TRAP 4.0 110 2
U5TRAP45 TRAP 4.5 100 0
U5TRAP45SH TRAP 4.5 100 2
U5TRAP45SHA TRAP 4.5 110 2



DXTerity™ TRA diagnostic catheter 6 Fr

Style Item number Curve size Length (cm) Sideholes
TRAcker U6TRACK TRACK 3.5 100 0
U6TRACKSH TRACK 3.5 100 2
U6TRACKSHA TRACK 3.5 110 2
U6TRACT TRACT 100 0
U6TRACTSH TRACT 100 2
U6TRACTSHA TRACT 110 2
TRAnsformer U6TRAN35 TRAN 3.5 100 0
U6TRAN35SH TRAN 3.5 100 2
U6TRAN35SHA TRAN 3.5 110 2
U6TRAN40 TRAN 4.0 100 0
U6TRAN40SH TRAN 4.0 100 2
U6TRAN40SHA TRAN 4.0 110 2
U6TRAN45 TRAN 4.5 100 0
U6TRAN45SH TRAN 4.5 100 2
U6TRAN45SHA TRAN 4.5 110 2
TRApease U6TRAP35 TRAP 3.5 100 0
U6TRAP35SH TRAP 3.5 100 2
U6TRAP35SHA TRAP 3.5 110 2
U6TRAP40 TRAP 4.0 100 0
U6TRAP40SH TRAP 4.0 100 2
U6TRAP40SHA TRAP 4.0 110 2
U6TRAP45 TRAP 4.5 100 0
U6TRAP45SH TRAP 4.5 100 2
U6TRAP45SHA TRAP 4.5 110 2
ULTRA U5ULTRA35 ULTRA 3.5 100 0
U5ULTRA35SH ULTRA 3.5 100 2
U5ULTRA35SHA ULTRA 3.5 110 2
U5ULTRA40 ULTRA 4.0 100 0
U5ULTRA40SH ULTRA 4.0 100 2
U5ULTRA40SHA ULTRA 4.0 110 2
U5ULTRA45 ULTRA 4.5 100 0
U5ULTRA45SH ULTRA 4.5 100 2
U5ULTRA45SHA ULTRA 4.5 110 2
U6ULTRA35 ULTRA 3.5 100 0
U6ULTRA35SH ULTRA 3.5 100 2
U6ULTRA35SHA ULTRA 3.5 110 2
U6ULTRA40 ULTRA 4.0 100 0
U6ULTRA40SH ULTRA 4.0 100 2
U6ULTRA40SHA ULTRA 4.0 110 2
U6ULTRA45 ULTRA 4.5 100 0
U6ULTRA45SH ULTRA 4.5 100 2
U6ULTRA45SHA ULTRA 4.5 110 2

Resources

Similar products

TM* Third-party brands are trademarks of their respective owners.

  1. Based on Acute Device Evaluation, D00169136 Medtronic transradial introducers & diagnostic catheters in porcine model.  February 2020.
  2. Based on Master Validation Plan (MVP) 10182446DOC, for Medtronic transradial braided shaft. May 2019.

  1. Based on usability study report 10131323DOC, radial access kit and diagnostic catheter. February 2014.
  2. Based on design verification report 10252455DOC, DxTerity 5F and 6F. April 2016.
  3. Based on radiopacity report 10291353DOC, DxTerity coronary and pigtail catheter. April 2016
